SPIDER CROSS LINER

SPIDER CROSS LINER

The Compact SPIDER Model, Designed for Both Home Users and Professionals.

from $9,998 (USD)

MSRP

up to 55°

CLIMBING ABILITY

up to 0.6 Acres/hr

PRODUCTIVITY

4-Wheel, 360°

DRIVE SYSTEM

Tailored to Your Specific Needs:

The SPIDER CROSS LINER is now available in 3 variants to better meet your unique requirements:

  • CROSS LINER HYDROTWIN: A new model with hydraulic skid-steering for easy handling and precise direction in challenging terrain.

  • CROSS LINER PREMIUM: Features a hydraulic winch for improved slope accessibility and enhanced performance.

  • CROSS LINER LITE: A cost-effective option without a winch, ideal for less demanding applications.

Key features include:

  • Innovative, Compact Design: Latest addition to the SPIDER product line.

  • Terrain-Copying Platform: Ensures smooth operation on uneven surfaces.

  • Powered by Honda Commercial Engine: Delivers reliable and powerful performance.

  • Optimized for Steep Slopes: Delivers perfect cut quality with enhanced stability from the integrated winch.

  • Based on Proven Models: Built on the legendary ILD01 and ILD02, incorporating further innovation.

Design & Features

All-Aluminum Chassis
Lightweight and corrosion-resistant for long-lasting durability.

Hardox Alloy Blade
Durable for quality mulching

CROSS LINER

Patented Drive System
All-directional mowing for maximum maneuverability.

Patented Winch System
For increased accessibility on steep slopes.

Technical Specifications

Type

CROSS LINER HYDROTWIN

CROSS LINER PREMIUM

CROSS LINER lite

MSRP

$17,998 (USD)

$14,998 (USD)

$9,998 (USD)

Engine

Honda GXV390

Honda GXV390

Honda GXV390

Performance

10.2 HP (7.6 kW)

10.2 HP (7.6 kW)

10.2 HP (7.6 kW)

Displacement

389 cc

389 cc

389 cc

Fuel Tank

1.05 gal.

1.05 gal.

1.05 gal.

Fuel

Unleaded Petrol

Unleaded Petrol

Unleaded Petrol

Transmission

Hydrostatic (Sauer Danfoss)

Hydrostatic (Sauer Danfoss)

Hydrostatic (M+S Hydraulic)

Oil Tank

1.05 gal.

1.05 gal.

1.05 gal.

Speed

0 – 3.7 mph

0 – 3.7 mph

0 – 3 mph

Drive

360°, 4-wheel drive

360°, 4-wheel drive

360°, 4-wheel drive

Skid-Steering

Hydraulic

Electric

Electric (Optional)

Tire Type

​13 × 5–6 (x-track)

13 × 5–6 (x-track)

13 × 5–6 (turf)

Cutting Width

25.6 in. (center blade)

25.6 in. (center blade)

25.6 in. (center blade)

Cutting Height

1.6 – 3.9 in.

1.6 – 3.9 in.

1.6 – 3.9 in.

Clutch

Mechanical with the brake

Mechanical with the brake

Mechanical with the brake

Productivity

Up to 0.6 acres/hr.

Up to 0.6 acres/hr.

Up to 0.5 acres/hr.

Fuel Consumption

0.4 gal./hr.

0.4 gal./hr.

0.4 gal./hr.

Climbing Ability

35°

55°

35°

Hydraulic Winch

No

Yes

No

Dimensions

39 × 44 × 24 in.

39 × 44 × 24 in.

39 × 44 × 24 in.

Gross Weight

360 lbs.

386 lbs.

360 lbs.

Application
